In our journey to build a scalable, maintainable, and robust event-driven microservice architecture, we made a fundamental decision early on: to abandon the traditional ActiveRecord pattern in favor of a more explicit approach combining Repository and Record patterns. This article explores why we made this choice and the significant benefits it has brought to our system.
The ActiveRecord pattern, popularized by frameworks like Ruby on Rails, combines data access and business logic into a single object. While this approach offers simplicity and rapid development for smaller applications, it introduces several challenges as systems grow:
Instead of ActiveRecord, we adopted a combination of two patterns:
Records are immutable value objects that represent data entities. They:
module Account
class Record < Verse: :Model: :Record: :Base
type “iam/accounts” # Used for JSON API serialization
field :id, type: Integer, primary: true
field :email, type: String
field :account_type, type: String
# Note: readonly keyword is used for reflection only, to generate update schema.
# A record is always a read-only structure
field :created_at, type: Time, readonly: true
field :updated_at, type: Time, readonly: true
field :password_digest, type: String, visible: false
belongs_to :person, repository: “Person: :Repository” , foreign_key: :person_id
has_many :roles , repository: “Account::Role: :Repository” , foreign_key: :account_id
end
end
Repositories handle data access and persistence. They:
module Account
class Repository < Verse::Sequel::Repository
self .table = “accounts” # Database table name
self .resource = “iam:accounts” # Type used for event publishing & security scoping
def scoped (action)
# Scope the resource accessible based on auth_context provided when
# creating the repository
auth_context.can!(action, self.class .resource) do |scope|
scope.all? { table }
scope.own? { table.where( id: auth_context.metadata[ :id ]) }
end
end
# Custom filter for `index` and `find_by` queries
custom_filter :role_name do |collection, value|
frag = <<-SQL
EXISTS (
SELECT 1
FROM account_roles
WHERE account_roles.account_id = accounts.id
AND account_roles.name IN (?)
)
SQL
value = [value] unless value.is_a?(Array)
collection.where(Sequel.lit(frag, value))
end
end
end
With ActiveRecord, it’s easy to modify an object and forget to save it, or conversely, accidentally persist changes:
# ActiveRecord approach
user = User.find( 1 )
user.email = “new@example.com” # Changed but not saved!
# … later in the code …
user.save # Oops, saved without realizing it had been changed
With our Record/Repository approach, all database operations are explicit:
# Repository/Record approach
user = user_repo.find ( 1 )
# user.email = “new@example.com” # Error! Records are immutable
updated_user = user_repo.update!( 1 , { email: new@example.com }) # Explicit database operation
This explicitness is crucial when database operations can be slow or expensive. There’s no ambiguity about when data is being read from or written to the database.
The N+1 query problem is a common performance issue with ActiveRecord:
# ActiveRecord approach – generates N+1 queries
users = User.all
users.each do |user|
puts user.posts # Each iteration triggers a new query
end
Our Repository pattern makes it almost impossible to fall into this trap because associations aren’t automatically loaded:
# Repository approach
users = user_repo.index({})
# users.each { |user| puts user.posts.count } # Error! No implicit loading
# Instead, you must explicitly include associations or use optimized queries
users_with_posts = user_repo.index({}, included: [ “posts” ])
users_with_posts.first.posts # It is accessible and loaded now.
# Or better yet, create a specific query method
users_with_post_counts = user_repo.index_with_post_counts
This forces developers to think about data access patterns upfront, leading to more efficient queries.
In ActiveRecord, complex query logic often gets mixed with business logic:
# ActiveRecord approach – query logic mixed with business logic
class User < ActiveRecord::Base
def self.active_premium_users_with_recent_activity
where( status: ‘active’ , plan: ‘premium’)
.joins( :activities )
.where( ‘activities.created_at > ?’ , 30 .days.ago)
.distinct
end
def can_access_premium_feature?
premium? && active?
end
end
Our approach cleanly separates these concerns:
# Repository – handles query logic
class User::Repository < Verse::Sequel::Repository
def active_premium_users_with_recent_activity
scoped( :read )
.where( status: ‘active’ , plan: ‘premium’)
.join( :activities, user_id: :id )
.where(Sequel[ :activities ][ :created_at ] > Sequel.lit( ‘NOW() – INTERVAL \’30 days\”))
.distinct
end
end
# Service – handles business logic
class UserService < Verse::Service::Base
use_repo repo: User::Repository
def can_access_premium_feature? (user_id)
user = repo.find(user_id)
user.plan == ‘premium’ && user.status == ‘active’
end
end
This separation makes code more maintainable and easier to test. It also allows for specialized optimization of queries without affecting business logic later in the development process.
One powerful feature of our approach is the ability to create “virtual” repositories that aren’t tied to a specific table but represent a projection or a complex query:
module QueryResult
class Repository < Verse::Sequel::Repository
attr_accessor :query_id
def initialize (auth_context, query_id, metadata: {})
super (auth_context, metadata:)
@query_id = query_id
end
# Redefine table as a query with complex from-clause.
def table
# Complex SQL query that joins multiple tables and calculates relevance scores
sql_statement = Sequel.lit(
complex_query_fragment,
query_id: query_id,
# other parameters…
)
client { |db| db.from(sql_statement) }
end
def scoped (action)
# Use this repo as a read-only repo
raise ArgumentError, “is read-only” unless action == :read
super
end
end
end
This allows us to encapsulate complex data access patterns in a clean, reusable way. The repository can handle the complexity of joining multiple tables, calculating derived values, or even accessing external services, while still presenting a consistent interface to the rest of the application.
In a microservice architecture, communication between services is crucial. Our repository pattern automatically publishes events to an event bus on mutative actions:
module Instance
class Repository < Verse::Sequel::Repository
self .resource = “quiz:instances”
event( name: “completed”)
def complete! (instance_id)
no_event do # Optionally, prevent the event `updated` to be published,
# as we replace it by `completed`
update!(
instance_id,
{
ended_at: Time.now,
status: “completed”
}
)
end
end
end
end
When complete! is called, it automatically publishes a “completed” event to the event bus after the database operation succeeds. Other services can subscribe to these events to react accordingly.
In Verse, the parameters passed to the repositories are sent to the event payload. In the case above, we will get an event quiz:instances:completed(resource_id=query_id, payload={})
The no_event block allows us to perform nested operations without triggering additional events, preventing event cascades.
In a distributed system with read replicas, it’s important to direct read queries to replicas and write operations to the master. Our approach makes this explicit:
module Instance
class Repository < Verse::Sequel::Repository
# Write operation – goes to master
def update_status!(id, status)
update!(id, { status: })
end
# Flag this method as read operation – can go to replica
query
def exists_for_quiz?(quiz_id)
scoped(:read)
.where(quiz_id: quiz_id)
.select(1)
.limit(1)
.any?
end
end
end
Methods marked with query are automatically routed to read replicas, while other methods go to the master. This simple annotation makes it easy to optimize database load without complex configuration or middleware.
There is a catch: In the case of a read action followed by a write, you can use Repository#with_db_mode(:rw, &block) to force usage of the master node.
Authorization is a cross-cutting concern that’s often awkwardly implemented in ActiveRecord. Our repository pattern elegantly handles this with scoped methods:
module Account
class Repository < Verse::Sequel::Repository
def scoped (action)
auth_context.can!(action, “iam:accounts”) do |scope|
scope.all? { table } # Admins can access all accounts
scope.by_ou? do # Scoped by organizational units, with the specific ou stored in the context itself
ou = auth_context[ :ou ]
auth_context.reject! unless ou
Service::TableQuery.by_related_ou(table, ou, related_table: :people, foreign_key: :person_id)
end
scope.own? { table.where( id: auth_context.metadata[ :id ]) } # Users can access their own account
end
end
end
end
This approach:
Let’s compare a typical ActiveRecord implementation with our Repository/Record approach for a common task: finding users with a specific role and updating their status.
# ActiveRecord implementation
class User < ActiveRecord::Base
has_many :roles
def self.with_role(role_name)
joins(:roles).where(roles: { name: role_name })
end
end
# Usage
admin_users = User.with_role(‘admin’)
admin_users.update_all(status: ‘active’)
Issues with this approach:
# Repository implementation
module User
class Repository < Verse::Sequel::Repository
self .table = “users”
self .resource = “iam:users”
def scoped (action)
auth_context.can!(action, “iam:users” ) do |scope|
scope.all? { table }
scope.own? { table.where( id: auth_context.metadata[ :id ]) }
end
end
custom_filter :role_name do |collection, value|
collection.join (:user_roles, user_id: :id ).where(Sequel[ :user_roles][:name ] => value)
end
event( name: “status_updated”)
def update_status_for_role! (role_name, status)
users = scoped( :update ).where( role_name: role_name)
# Prevent `updated` event to be triggered, supersed by `status_updated`
no_event{ users.update!( status: status) }
end
end
end
# Usage
user_repo.update_status_for_role!( ‘admin’, ‘active’)
Benefits of this approach:
Switching from ActiveRecord to the Repository/Record pattern has been transformative for our microservice architecture. While it required more upfront design and slightly more code, the benefits have far outweighed the costs:
For complex, distributed systems, especially those with microservice architectures, the explicitness and separation of concerns provided by the Repository/Record pattern offer significant advantages over the traditional ActiveRecord approach.
In future articles, we’ll dive deeper into specific aspects of our architecture:
Have you experimented with alternatives to ActiveRecord in your projects? We’d love to hear about your experiences and challenges. Share your thoughts in the comments below or reach out to our team to discuss how these patterns might benefit your architecture.
This article is part of our series on event-driven microservice architecture. Stay tuned for more insights into how we’ve built a scalable, maintainable system.
